How does automated sample preparation reduce turnaround time in testing labs?

Automated sample preparation reduces turnaround time in testing labs by replacing slow, labor-intensive manual steps with parallel, programmable workflows that run continuously without operator intervention. Systems like automated SPE platforms and cleanup units can process dozens of samples simultaneously, cutting preparation time from days to hours. The sections below break down exactly where time is lost in manual workflows, how automation recovers it, and when the investment makes practical sense.

What steps in sample preparation take the most time in a testing lab?

The most time-consuming steps in laboratory sample preparation are extraction, lipid removal and cleanup, solvent evaporation, and concentration. These stages are not only slow when performed manually but also require constant operator attention, making them the primary bottleneck in any analytical workflow for environmental contaminants.

Extraction alone can take many hours depending on the matrix. Soxhlet-based methods for solid samples such as soil, feed, or sludge traditionally require overnight runs. Cleanup of co-extracted matrix components, particularly lipids in food and feed samples, demands multiple sequential column passes. Each step introduces waiting time, and when done manually, only one analyst can realistically manage a small number of samples at once.

Solvent evaporation and concentration to a precise injection volume are frequently underestimated time sinks. After cleanup, extracts must be reduced to exact volumes suitable for GC injection, and doing this manually with rotary evaporators or nitrogen blowdown for large batches is both slow and inconsistent. Any inconsistency at this stage can force reruns, compounding delays further.

How does automation speed up extraction and cleanup workflows?

Automation speeds up extraction and cleanup workflows by running multiple samples in parallel, eliminating idle waiting periods between steps, and executing programmed sequences without operator involvement. A fully automated system can work overnight or across a weekend, delivering ready-to-inject extracts when analysts return to the lab.

In extraction, automated systems based on the Randall principle, such as the SER-158, perform boiling solvent extraction followed by a hot Soxhlet step and simultaneous concentration in a single unattended run. Up to six solid or semi-solid samples can be extracted in approximately 23 hours using less than 100 mL of solvent per sample, with solvents recovered in a dedicated tank rather than released into the lab environment.

For cleanup of persistent organic pollutants, fully automated platforms like the GO-EHT systems from Miura Institute of Environmental Science carry out the entire purification sequence, including lipid removal and multi-column fractionation, without any manual intervention between steps. Because samples never come into direct contact with the system itself, carryover between runs is eliminated, removing one of the most common causes of repeated analysis. The result is a predictable, consistent output that shortens the time from sample receipt to reportable result.

What’s the difference between automated and manual SPE in terms of throughput?

Automated SPE systems deliver significantly higher throughput than manual SPE by processing multiple samples simultaneously across parallel channels, maintaining consistent flow rates, and operating without breaks. Manual SPE is typically limited to one or a few samples per analyst at a time and is prone to variability that reduces first-pass success rates.

In practical terms, the difference is substantial. A manual SPE workflow for PFAS or pesticide analysis in water might allow an experienced analyst to process eight to twelve samples in a full working day. An automated platform like the SPE2000 can process up to 80 samples in a single run across ten consecutive sequences of eight samples simultaneously, handling sample volumes from 10 mL up to 1,000 mL and accommodating 1 mL, 3 mL, 6 mL, and 12 mL cartridges.

For large-volume water samples, multi-channel systems such as the AutoEmpore operate in 3-, 6-, 9-, or 12-channel configurations in parallel or series mode, with automatic online filtration and water removal built in. These capabilities fundamentally change what a single analyst can achieve in a day, allowing labs to scale throughput without proportionally scaling headcount.

Can automated sample preparation reduce cross-contamination and reruns?

Yes, automated sample preparation significantly reduces cross-contamination and the reruns it causes. When samples do not come into direct physical contact with shared instrument components, carryover between samples is eliminated by design rather than managed through cleaning protocols that can fail.

In manual workflows, shared glassware, columns, and transfer vessels are a persistent source of contamination risk, particularly for ultra-trace analytes like dioxins, PCBs, and PFAS, where contamination at the parts-per-trillion level can invalidate results. Each rerun triggered by contamination does not just cost reagents and time; it delays every other sample in the queue.

Automated cleanup systems designed for persistent organic pollutant analysis address this structurally. The GO-EHT platform, for example, is engineered so that samples do not contact the system directly, eliminating the primary contamination pathway. For PFAS analysis specifically, LabTech’s SPE systems feature fully inert flow paths free of Teflon, removing a common source of background contamination that has historically compromised PFAS results at low concentration levels. Fewer contamination events mean fewer reruns, more predictable scheduling, and a measurable improvement in overall laboratory efficiency.

Which contaminant analyses benefit most from automated sample prep?

The contaminant analyses that benefit most from automated sample preparation are those involving persistent organic pollutants (POPs) such as dioxins, PCBs, PBDEs, and PFAS, as well as pesticides and PAHs. These analyses share common characteristics: complex, multi-step cleanup requirements, very low detection limits, and strict regulatory acceptance criteria that leave no room for variability.

Dioxin and PCB analysis is among the most demanding in any environmental or food safety laboratory. Samples require lipid removal, multi-column fractionation, and precise fraction collection before GC-HRMS injection. Automating this sequence with systems like the GO-EHT not only saves time but also delivers the reproducibility that accredited laboratories need to maintain ISO 17025 compliance across large sample batches.

PFAS analysis presents a different but equally compelling case. The analytes are ubiquitous, which means contamination from lab materials, solvents, and shared equipment is a constant risk. Automated SPE with inert, Teflon-free flow paths directly addresses this. Pesticide residue analysis in food and feed benefits from automated SPE throughput, particularly when laboratories must screen large numbers of samples against broad multi-residue panels under tight regulatory deadlines. PAHs, SVOCs, hormones, and other emerging contaminants in water also gain substantially from automated large-volume extraction platforms.

When does automated sample preparation become cost-effective for a lab?

Automated sample preparation becomes cost-effective when the combined savings in analyst time, solvent costs, and rerun reduction offset the system investment, which typically occurs when a laboratory processes more than a few dozen samples per week in contaminant categories that require multi-step cleanup. For high-throughput or accredited labs, the break-even point often arrives faster than expected.

The calculation involves several factors. Analyst time is usually the largest cost driver. When a skilled analyst spends the majority of their working hours on repetitive extraction and cleanup tasks rather than on data review, method development, or client communication, the opportunity cost is significant. Automation reclaims those hours and allows the same headcount to handle a larger sample volume.

Solvent costs and waste disposal fees are a secondary but meaningful factor. Automated systems designed for green chemistry, such as those using less than 100 mL of solvent per sample without dichloromethane, reduce both procurement costs and the regulatory burden of hazardous waste disposal. Over hundreds of samples per year, these savings accumulate.

Finally, the cost of reruns and failed batches must be factored in. A single failed dioxin analysis batch can represent many hours of lost work and delayed client reporting. Laboratories that have moved to automated workflows consistently report fewer reruns due to the reproducibility and contamination control that automation provides. For ISO 17025-accredited labs operating under proficiency testing requirements, that reliability also protects accreditation status, which carries its own financial and reputational value.

How DSP-Systems helps laboratories reduce turnaround time

DSP-Systems supplies and configures automated sample preparation systems specifically designed for laboratories analyzing environmental contaminants under regulatory pressure. Their portfolio addresses every stage of the preparation workflow:

Extraction: The SER-158 automates solid and semi-solid sample extraction using the Randall principle, processing up to six samples in 23 hours with minimal solvent use
Cleanup and purification: The GO-EHT systems from Miura automate full purification for dioxins, PCBs, PBDEs, and PCNs across food, feed, soil, water, and air matrices
SPE for PFAS and pesticides: The SPE2000 and AutoEmpore handle high-throughput solid-phase extraction with inert, Teflon-free flow paths suited for PFAS and other emerging contaminants
Concentration: The CentriVap, MultiVap 64, and MultiVap 12 systems automate solvent evaporation and final volume adjustment after cleanup
Configuration and support: DSP-Systems provides pre-installation programming, SPE application testing, and configuration aligned with EPA and CEN standards

Whether you are building a new analytical capability or scaling an existing workflow, DSP-Systems can help you identify the right combination of systems for your sample types and throughput targets. Contact DSP-Systems to discuss your laboratory’s requirements and request a tailored recommendation.

Veelgestelde vragen

How long does it typically take to transition a manual sample prep workflow to a fully automated one?

The transition timeline depends on the complexity of your existing workflow and the number of sample types involved, but most laboratories can implement a single automated system — such as an SPE platform or automated cleanup unit — within a few weeks of installation, including method transfer and operator training. Pre-configured systems supplied with application-specific programming, like those offered by DSP-Systems, significantly shorten the validation phase. For ISO 17025-accredited labs, you will also need to document the method transfer and demonstrate equivalency to your existing accredited procedure, which typically adds a few weeks but is straightforward when the automated system delivers equal or better reproducibility.

Can automated sample preparation systems handle low-frequency, mixed-matrix workloads, or are they only practical for high-volume, single-matrix labs?

Modern automated systems are designed with flexibility in mind and can accommodate mixed-matrix workloads, making them practical even for labs that process a variety of sample types such as water, soil, food, and feed within the same week. Platforms like the SPE2000 support a wide range of cartridge volumes and sample sizes, while GO-EHT systems are validated across multiple matrices for the same contaminant classes. The key is configuring the system with the appropriate method programs for each matrix upfront, after which switching between sample types requires minimal operator input.

What happens if an automated system encounters an error mid-run — will the entire batch be lost?

Most modern automated sample preparation platforms include error detection and logging features that stop the run at the point of failure rather than continuing and potentially corrupting the entire batch. Depending on the system and the nature of the error — such as a blocked cartridge, insufficient solvent volume, or a pressure anomaly — it may be possible to resume or salvage part of the batch. This is one reason why selecting a system with robust diagnostics and responsive technical support, including remote troubleshooting capabilities, is an important part of the purchasing decision.

How do automated systems perform against regulatory method requirements like EPA 3500 series or CEN standards?

Automated sample preparation systems can be configured to comply with specific regulatory methods, including EPA 3500-series extraction methods and CEN standards for food, feed, and environmental matrices. Suppliers like DSP-Systems provide pre-installation programming and SPE application testing aligned with these standards, so the system is validated for regulatory use before it enters your workflow. It is still the laboratory’s responsibility to verify performance against their specific accreditation requirements, but automated systems typically make this easier by delivering the reproducibility and documentation trails that regulatory bodies expect.

What are the most common mistakes labs make when first implementing automated sample preparation?

The most common mistake is underestimating the importance of method transfer — assuming that a manual method can be directly replicated on an automated platform without any optimization. Flow rates, cartridge conditioning volumes, and solvent timing often need adjustment to match the automated system’s mechanics. A second frequent issue is insufficient training: operators who understand only the basic run sequence but not the underlying chemistry are poorly equipped to troubleshoot when results deviate. Working closely with your system supplier during the commissioning phase, including hands-on application testing with your actual sample matrices, is the most effective way to avoid both pitfalls.

Is it possible to automate only part of the sample preparation workflow, or does automation require an all-or-nothing investment?

Partial automation is not only possible but is often the most practical starting point for laboratories working within budget constraints or evaluating automation for the first time. Many labs begin by automating the single biggest bottleneck in their workflow — most commonly SPE or solvent evaporation — and then expand to adjacent steps as ROI is confirmed. Modular systems are designed to integrate with both manual upstream steps and downstream instruments, so you can build a fully automated pipeline incrementally rather than all at once.

How do solvent savings from automated systems compare to manual workflows in practice, and do they meaningfully offset system costs?

In practice, automated systems designed around green chemistry principles can reduce solvent consumption by 50–70% compared to equivalent manual workflows, primarily by eliminating over-use during manual transfers, column conditioning, and cleanup steps. For a lab running hundreds of dioxin or PCB samples per year, this can translate into thousands of euros in combined solvent procurement and hazardous waste disposal savings annually. While solvent savings alone rarely cover the full system cost, they contribute meaningfully to the overall ROI calculation alongside analyst time recovery and rerun reduction — and they also reduce regulatory exposure associated with hazardous waste handling.
