Can automated sample preparation be customized for niche testing applications?

Yes, automated sample preparation can be customized for niche testing applications. Modern automated platforms are designed with configurable parameters, interchangeable components, and programmable workflows that allow laboratories to tailor extraction, cleanup, and concentration steps to specific analytes, matrices, and regulatory requirements. The sections below address the most common questions laboratories ask when evaluating customized automation for specialized contaminant analysis.

Which testing applications benefit most from customized automation?

Testing applications involving complex matrices, trace-level analytes, or strict regulatory thresholds benefit most from customized automated sample preparation. These include dioxin and PCB analysis in food and feed, PFAS testing in water and soil, pesticide residue screening, and persistent organic pollutant (POP) monitoring across environmental samples. In each case, the combination of high sensitivity requirements and matrix complexity makes a one-size-fits-all approach unreliable.

Laboratories conducting dioxin analysis or PCB analysis face particularly demanding cleanup requirements. Co-extracted lipids and matrix interferences must be removed before mass spectrometry measurement, and the purification steps involved are highly specific to the sample type. Similarly, PFAS testing demands inert flow paths and precise fraction collection to avoid background contamination from system components. Pesticide residue work spans dozens of target compounds across highly variable matrices, from leafy vegetables to animal fat, requiring flexible method programming rather than fixed protocols.

Environmental monitoring programs add another layer of complexity. Air, sediment, sludge, and water samples each behave differently during extraction and cleanup. Customized automation allows laboratories to apply matrix-specific parameters while maintaining the reproducibility and throughput that manual methods cannot consistently deliver at scale.

How does automated sample preparation adapt to different sample matrices?

Automated sample preparation systems adapt to different sample matrices through configurable extraction conditions, interchangeable cartridge formats, adjustable solvent volumes, and programmable sequence logic. Rather than applying a fixed protocol to every sample type, well-designed systems allow operators to define matrix-specific parameters that govern flow rates, solvent composition, fraction volumes, and cleanup steps.

For solid and semi-solid matrices such as soil, sludge, feed, or fatty food products, extraction systems based on the Randall principle can perform solvent extraction directly in boiling solvent, followed by hot Soxhlet or Twisselmann steps. This approach achieves high analyte recovery while using less than 100 mL of solvent per sample, which is significant for both cost and environmental impact. The GO-EHT purification platform is specifically engineered to handle this diversity, processing food, feed, soil, sewage, sludge, water, and air samples within a single automated framework.

For liquid matrices such as drinking water or surface water, large-volume extraction requires different tooling. Disk-based SPE systems with automatic online filtration and water removal handle the high sample volumes and particulate loads common in environmental water testing. The key to matrix adaptability is modular design: systems that support multiple disk sizes, cartridge formats, and parallel or series processing modes give laboratories the flexibility to switch between matrix types without rebuilding their workflow from scratch.

What are the limitations of one-size-fits-all sample prep systems?

One-size-fits-all sample preparation systems are limited by their inability to accommodate the specific cleanup requirements, solvent compatibility constraints, and analyte sensitivity thresholds that niche testing applications demand. When a system applies the same protocol regardless of matrix or target compound, the result is often compromised recovery, increased background interference, or the need for additional manual steps that negate the efficiency gains of automation.

Several specific limitations emerge in practice:

Inadequate matrix-specific cleanup: A generic cleanup protocol may not remove co-extracted lipids, pigments, or sulfur compounds that interfere with trace-level detection of dioxins or PCBs.
Solvent incompatibility: Systems with Teflon or non-inert components are unsuitable for PFAS testing because the materials themselves contribute background contamination at the sub-parts-per-trillion levels required.
Fixed fraction volumes: If a system cannot adjust the volume of collected fractions, it cannot meet the precise end-volume requirements for GC injection or the concentration steps that follow cleanup.
Limited cartridge compatibility: Systems locked to a single cartridge size cannot process the full range of sample volumes encountered across environmental and food safety workflows.
Throughput bottlenecks: A system optimized for one matrix type may become the rate-limiting step when a laboratory expands into new application areas without reconfiguring the workflow.

These limitations become commercially significant when a laboratory must either turn away niche testing work or process samples manually alongside automated runs, which undermines the business case for automation entirely.

Can automated SPE systems be configured for PFAS-specific workflows?

Yes, automated SPE systems can be configured specifically for PFAS workflows, but the configuration must address two non-negotiable requirements: a fully inert flow path free of Teflon or PTFE components, and the ability to process large sample volumes with precise fraction collection. Standard SPE systems that use fluoropolymer tubing or fittings introduce PFAS background contamination that renders results unreliable at the ultra-trace levels regulators now require.

PFAS-specific SPE automation typically involves large-volume water extraction, where sample volumes can range from several hundred milliliters to a liter or more. Systems supporting multiple disk formats (25 mm, 47 mm, and 90 mm) alongside smaller cartridges give laboratories the flexibility to handle both environmental water and more concentrated matrices such as food extracts or leachates. Automatic online filtration is particularly valuable for surface water or wastewater samples, where particulate matter would otherwise clog cartridges and disrupt the extraction sequence.

Beyond hardware configuration, PFAS workflows benefit from programmable sequence logic that controls conditioning, loading, washing, and elution steps independently for each sample position. This allows the system to apply different protocols within a single run, which is essential when a laboratory processes multiple sample types simultaneously. The SPE2000 platform, for example, supports up to 80 samples per run across 10 consecutive sequences, with compatibility for 1 mL through 12 mL cartridges and sample volumes from 10 mL up to 1,000 mL, making it a practical choice for high-throughput PFAS testing environments.

How do laboratories validate customized automated methods for regulatory compliance?

Laboratories validate customized automated methods for regulatory compliance by demonstrating that the automated workflow meets the same performance criteria as the reference method it replaces or implements. This means running recovery experiments, precision studies, and matrix-matched calibration to show that the automated system delivers results within the acceptance limits defined by applicable EU regulations, EPA methods, or CEN standards.

The validation process for customized automated sample preparation typically covers:

Recovery and reproducibility: Spiked samples at relevant concentration levels are processed through the automated workflow, and recovery rates are compared against method-specific acceptance criteria.
Selectivity and specificity: The cleanup performance of the automated system is evaluated to confirm that matrix interferences are removed to levels that do not compromise quantification.
Ruggedness testing: Parameters such as flow rates, solvent volumes, and cartridge lots are deliberately varied to identify the boundaries within which the method remains valid.
System suitability: Ongoing quality control samples are run alongside batches to confirm that the automated system performs consistently over time.

ISO 17025-accredited laboratories have a particular advantage here because their quality management systems already require documented method validation and ongoing proficiency testing. When introducing automated sample preparation into an accredited scope, the laboratory must demonstrate to its accreditation body that the automated method is equivalent to or better than the previously validated approach. Working with a supplier that provides pre-installation programming and application-specific testing against EPA and CEN standards significantly reduces the validation burden, because much of the method development work has already been completed and documented.

When should a laboratory choose a fully automated system over a semi-automated one?

A laboratory should choose a fully automated system over a semi-automated one when sample throughput, analyst safety, or reproducibility requirements exceed what semi-automated workflows can reliably deliver. Full automation is justified when the laboratory processes high sample volumes routinely, when the analytes involved require extended unattended processing, or when manual intervention at any stage introduces unacceptable variability.

Semi-automated systems are a reasonable choice when sample volumes are low, when the laboratory is building capability in a new application area and needs operational flexibility, or when budget constraints make a phased approach necessary. They can also serve as a bridge technology while a laboratory gathers the data needed to justify full automation to management or procurement.

Full automation becomes the clear choice under the following conditions:

High throughput requirements: When a laboratory needs to process dozens of samples per day consistently, manual steps become the bottleneck regardless of how efficient the instrumentation is.
Overnight or unattended operation: Fully automated systems can run cleanup and extraction sequences without operator presence, which multiplies effective laboratory capacity without adding headcount.
Solvent and safety considerations: Applications requiring extended solvent exposure benefit from full automation because analyst contact with organic solvents is minimized or eliminated.
Cross-contamination risk: In dioxin and PCB analysis, where samples do not contact the system directly in fully automated platforms, the risk of carryover between samples is structurally eliminated rather than managed through procedural controls.
Regulatory audit readiness: Fully automated systems generate electronic records of every processing step, which supports data integrity requirements under regulatory frameworks such as EU food safety legislation or EPA method compliance.

The decision ultimately comes down to whether the laboratory’s workload and quality requirements justify the investment. For laboratories running accredited contaminant testing at scale, the operational and compliance advantages of full automation typically outweigh the higher upfront cost within a relatively short time frame.

How DSP-Systems helps laboratories implement customized automated sample preparation

DSP-Systems works directly with laboratories to configure, validate, and deploy automated sample preparation solutions tailored to their specific testing applications. Whether the need is for dioxin and PCB cleanup, PFAS extraction, or multi-contaminant workflows across complex matrices, DSP-Systems offers:

Fully automated purification systems for POP analysis, including the GO-EHT platform for dioxins, PCBs, PBDEs, and PCNs across food, feed, soil, water, and air matrices
Automated SPE systems with inert, Teflon-free flow paths for PFAS, pesticide, and emerging contaminant applications
Pre-installation programming and application-specific configuration aligned with EPA and CEN method requirements
Method development and validation support in cooperation with ISO 17025-accredited laboratories
Training courses and turnkey laboratory setups for organizations building or scaling contaminant testing capabilities

If your laboratory is evaluating automated extraction systems or needs guidance on which platform fits your specific matrix and analyte requirements, contact DSP-Systems to discuss your application in detail.

Veelgestelde vragen

How long does it typically take to implement and commission a customized automated sample preparation system?

Implementation timelines vary depending on system complexity and the degree of method customization required, but most laboratories can expect a process spanning 4 to 12 weeks from order confirmation to operational deployment. This typically includes pre-installation programming, hardware configuration, on-site installation, and application-specific testing. Working with a supplier that delivers pre-configured systems validated against relevant EPA or CEN methods significantly compresses this timeline, since method development work is completed before the system arrives in the laboratory.

Can a single automated platform handle multiple contaminant classes, or does each application require a dedicated system?

Modern modular automated platforms are designed to handle multiple contaminant classes within a single system, provided the hardware configuration and programmable workflows support the required matrix and analyte combinations. For example, a platform capable of processing dioxins and PCBs in food matrices can often be reconfigured for pesticide residue or PBDE analysis by adjusting solvent sequences, cartridge formats, and fraction collection parameters. The key consideration is whether the system’s materials of construction and flow path design are compatible across all target applications — particularly when PFAS testing is involved, where inert, Teflon-free components are non-negotiable.

What happens when a new regulatory method is introduced — can existing automated workflows be updated without replacing the system?

In most cases, yes — well-designed automated sample preparation systems can be updated through software reprogramming and, where necessary, minor hardware adjustments such as cartridge format changes or additional solvent lines. This is one of the key advantages of programmable, modular platforms over fixed-protocol systems. When a regulatory body updates acceptance criteria or introduces a revised method standard, the laboratory’s supplier should be able to provide updated method files or configuration guidance rather than requiring capital reinvestment in new equipment.

How do automated sample preparation systems handle samples with highly variable matrix fat content, such as animal feed or fatty food products?

Automated systems designed for high-fat matrices typically address fat content variability through programmable cleanup sequences that adjust solvent volumes, column loading parameters, and the number or type of cleanup cartridges applied based on the expected fat load of the sample type. Gravimetric lipid determination prior to cleanup can be integrated into the workflow to trigger matrix-specific protocols automatically. For dioxin and PCB analysis in fatty matrices, multi-layer column cleanup — combining silica, alumina, and activated carbon sorbents — is often programmed as a sequential automated step to ensure consistent interference removal regardless of fat content variation between individual samples.

What are the most common mistakes laboratories make when transitioning from manual to automated sample preparation?

The most common mistake is attempting a direct one-to-one transfer of a manual method into an automated workflow without accounting for differences in flow dynamics, solvent delivery precision, and cartridge conditioning behavior between manual and automated processing. Laboratories that skip a dedicated method transfer and optimization phase often see recovery or reproducibility issues that are incorrectly attributed to the automation platform itself. A second frequent error is underestimating the importance of system suitability checks and ongoing QC integration — automation improves consistency, but it does not eliminate the need for routine performance verification, particularly under ISO 17025 or regulatory compliance frameworks.

Is automated sample preparation cost-effective for smaller laboratories with lower sample volumes?

Cost-effectiveness for lower-volume laboratories depends heavily on the analyte and matrix complexity rather than sample volume alone. For high-value niche testing such as dioxin analysis or PFAS monitoring, even a modest throughput of samples per week can justify automation when the alternative is labor-intensive manual cleanup that limits analyst availability for other work. Semi-automated systems offer a lower entry point and can deliver meaningful reproducibility and solvent reduction benefits at lower throughput levels. A practical approach is to model the total cost of ownership — including analyst time, solvent costs, repeat analysis rates, and potential revenue from niche testing contracts — against the system investment to determine the break-even point for your specific workload.

How should a laboratory evaluate whether a supplier's automated system is genuinely configurable versus marketed as flexible but rigid in practice?

The most reliable way to evaluate genuine configurability is to request a live demonstration using your actual sample matrix and target analytes, rather than a standard application the supplier has pre-optimized for demonstration purposes. Ask specifically whether flow rates, solvent volumes, fraction collection windows, and cartridge formats can be independently adjusted through the software interface without vendor intervention, and whether method files can be created or modified in-house after initial training. Requesting references from laboratories running similar niche applications — particularly those operating under ISO 17025 accreditation — provides real-world evidence of how the system performs outside controlled demonstration conditions.
